|Frame:||Anodized Aluminum||Separator:||Hot Glue|
|Application:||Termina Of HVAC System||Class:||H13|
custom air filters,
air purifier washable hepa filter
H13 Disposable Terminal HEPA Filter Unit, Non Motorized Type
Disposable Terminal HEPA filter is by coordinating with the use of ceiling T-bar system, the disposable HEPA filter module unit can connect to air hose directly.
As for its small size, light weight, easy assembling, saving the installation time, it can be used for clean room or the other critical clean area which its cleanliness level is between class 1 and class 100,000.
Customized sizes and specifications are available to meet customer's requirements.
Low pressure drops
Thin in depth
Adjustable air flow
Negative pressure sealing
It is considered especially suitable for applications in the ventilation and air conditioning system with limited space.
Material and operating conditions:
|Filter media||Fiberglass or HV fiberglass|
|Initial drop||≤220pa or 120pa|
|Maximum operating temperature||80℃|
|Maximum operating humidity||80%|
Standard size and specifications:
|Model||Outside dimensions(mm)||Rated air flow (m3/h)||Collar size|
|ZS-GY610||610x610x150||1000||200 mm ( 8")|
|ZS-GY915||915x610x150||1500||250mm ( 10")|
|ZS-GY1170||1170x570x150||1800||300mm ( 12")|
|ZS-GY1220||1220x610x150||2000||300mm ( 12")|
Pictures of Disposable Terminal HEPA filter:
40% prepayment by T/T at order, the balance of payment before shipment.
Carton and Plywood Case
• Production period:15-30days
• Shipping notice or insurance for you after the goods is shipped.
After sales service:
• We respect your feed back after receive the goods.
• We provide 1 year warranty after goods arrive.
• We care of your complain within 48hours.
Contact Person: Miss. Rita Guo
