2 Side Blowing PLC Control Stainless Steel 304 Air Shower Room

2 Side Blowing PLC Control Stainless Steel 304 Air Shower Room

MOQ: 1 set
Standard Packaging: plywood case
Delivery Period: about 15 days upon receipt of deposit
Payment Method: T/T, Western Union
Supply Capacity: 200 Set/Sets per Month
Detail Information
Place of Origin
Guangdong, China (Mainland)
Brand Name
Zhisheng
Certification
ISO 9001/CE/ROHS
Model Number
ASS-1400D-1
Condition:
New
Dimension(WxDxH):
W1400xD1000xH2100mm
In Size(MM):
W800xD900xH1960mm
Blowing Side:
2- Side Blowing
Material:
T=1.2 Stainless Steel 304
Suitable:
One Person
Voltage:
AC380V, 50 Hz, 3PH
Minimum Order Quantity:
1 set
Packaging Details:
plywood case
Delivery Time:
about 15 days upon receipt of deposit
Payment Terms:
T/T, Western Union
Supply Ability:
200 Set/Sets per Month
High Light:

Stainless Steel 304 Air Shower Room

,

2 Side Blowing Air Shower Room

,

PLC Control Stainless Steel Air Shower

Product Description

High Standard Air shower room as entrance unit between clean room and non-clean room​



Air shower.pdf



People wear clean room clothes and shoes, open the entrance door of air shower, enter inside, close the entrane doors, it is blowing automatically, and it is has human voice prompt when it is blowing, the clean air at 25m/s which remove the dust particles and bacterias from peoples body, after blowing (air shower), then open the exit door and go into clean room, exit door will be closed auotmatically by the door closer. Two doors are interlocked, which cannot open at the same time. However, if it is power off or press the E-stop switch, the electric locks of two doors will be unlocked, people can open the doors and  go it out.



According to the blowing method, the air shower room can be divided into: top air shower room, single-side blowing air shower room for one person, double-side blowing air shower room for 2 persons,Three-side blowing air shower room for one person, double-side blowing air shower room for 2 persons, Double-side blowing air shower room for multi-persons, L type air shower room,


According to the material of the casing:the air shower room can be divided into: stainless steel air shower, powder coated steel air shower.


According to the degree of automation, the air shower can be divided into: intelligent voice air shower, automatic door air shower, explosion-proof air shower, fast rolling door air shower


Air shower room can be divided according to different objects:Personal air shower room, cargo shower room, air shower tunnels, cargo shower tunnels.



Features:



The two doors of the automatic air shower are electronically interlocked and can function as an air lock chamber to prevent external pollution and unpurified air from entering the clean area.



Eliminate the staff to bring hair, dust, bacteria into the workshop, to meet the strict dust-free workshop purification standards of the workplace, meet the production environment pollution requirements, and produce high-quality products.





Size and Specifications:





Product One Person Air Shower
External size W1400xD1000xH2100mm
Internal size W800xD900xH196mm
Material: T=1.2 mm stainless steel 304
Doors type W=800mm single-leaf SS304 swing doors
Door closer 2 SETs
Electric lock 2 SETs
Indicator lights Green / Red/Yellow
Blower fan 2sets,capacity: 2500CMH/set
99.99% HEPA filter 610*610*69mm 2 pcs
Pre filter 1 pcs
Nozzle 8+8=16pcs
Bloweing type 2 -side blowing, wind speed: >24m/s
Control system Control by PLC control system and LCD touch screen
Photoelectric snesor Omron brand 1pcs
Philips LED light 1x18W





Metal Indicator light -----Good-looking, high quality



2 Side Blowing PLC Control Stainless Steel 304 Air Shower Room 0

Lock Screws---It is easy for opening the panel inside and maintain air shower.

2 Side Blowing PLC Control Stainless Steel 304 Air Shower Room 1



2 Side Blowing PLC Control Stainless Steel 304 Air Shower Room 2
