Clean Room Air Shower System With Auto Sliding Doors For People And Goods
Clean Room Air Shower With Auto Sliding doors:
1) Automatic sliding doors will be open and close automatically.
2) Automatic blowing
3) 100 class cleanroom
4) Wind speed:22-25/s
With Automatic sliding doors
Clean Room Air shower is mainly composed of cabinet, fans, filters, nozzle, electric control system of five parts. Main body is made by 1.2mm cold plate coating, stainless steel for the base.
Automatic air shower room adopts photoelectric control, electric interlock, automatic blow. Air shower time is adjustable, compact structure, easy to use.
the operator is maximum dust source in working space , Air shower room, a purifying equipment being able to clean the dust adhering to the surface of human body and articles,
preventing the unclean air invade into the clean room.
To meet the cleanliness requirement of clean room with the help of air-conditioning system in the clean room.
1. The control system: LCD control panel with human voice, electronic interlock and automatic blowing
2. Air shower time from 0 to 99 seconds which can be adjustable
3. Adopt Pre filter and HEPA filter
4. The case adopts high quality cold rolled steel with powder coated or stainless steel
5. The door, bottom-board, nozzles are used of stainless steel, good appearance.
6. When air shower is used to pass cargo, it is without bottom-board.
1. Double-leaf or single-leaf automatic-sliding doors by photoelectric sensor (when person enter air shower, the door will open automatically, go out air shower,
the door will be closed automatically.)
2. HEPA filter or ULPA filter
3. The case is used of cold-rolled steel plate / all stainless steel air shower / just stainless steel inside
4. Common fluorescent lamp / UV Sterilizer lamp
Clean Room Air Shower With Auto Sliding doors for both people and goods
|Material for Cabinet||Power coated for mainbody, stainles steel for bottom|
|Material for Doors||Stainless steel frame with half glass|
|Door type||W800mm Automatic sliding doors|
|Blowing way||2- side blowing|
|Control system||English IC intelligent control panel with English human voice|
|HEPA filter efficinecy:||H13 (EN1822)|
|Pre filter||G3 (EN799)|
|Photoelectric sensor||OMRON brand|
|Shower time||0-99s adustable|
|Spurt wind speed||20-25m/s above|
|Power supply||AC 380V/50HZ/3PH|
|Safeguard||Leakage switch and thermal overload relay (Protect people from electric leakage)|
Packing: Plywood Case
Testing in factory:
All of equipment will be individually tested for safety and performance in accordance with international
Standards before shipment. Each unit is shipped with a documentation outlining the tests undertaken and
the units individual results for each unit.
Testing before shipment:
1. Appearance inspection
2. Electrical safety tests
3. Air wind speed testing
4. Function testing
The warranty of our equipment is for 1 year, but excluding consumable parts and accessories.
All equipment is shipped with a comprehensive use’s manual with testing report.
Additional IO/OQ/GMP document is available upon request.
Contact our sales representative for specific warranty details or document request.
1. HEPA filter: It should be changed in half or one year once.
2. Pre filter: It should be changed in 3-6 month once.
Air Shower Questions:
The below questions will help establish what air shower you need:
1. Is the air shower being used to enter a clean room environment?
2. Is the air shower being used to exit a contaminated enviroment?
3. Will the air shower be washed down or cleaned with harsh chemicals?
4. Will the air shower be used in a food processing facility?
5. How Mnay people will be going through the air shower at a given priod of time?
Why you choose ZHISHENG Company ?
Fast reply in 12 hours if we receive any inquiry or request from customer
Familiar with equipment.
Technician or enginner can go to Southeast Asian countries for guiding insallation of machines. Like Thailand, Vietnam, Philipines, Malaysia and so on.
• Production period:15-30days
• Shipping notice or insurance for you after the goods is shipped.
After sales service:
• We respect your feed back after receive the goods.
• We provide 1 year warranty after goods arrive.
• We promise all spare parts available in lifetime use.
• We care of your complain within 48hours.
30% prepayment by T/T at order, the balance of payment before shipment.
Cleanroom equipments,like air shower, FFU. It is one-year warranty.
We have CE and ROHS Certificate for air shower
