Vertical Clean Room Air Showers With Aluminum Swing Doors Control By IC Control Panel

Vertical Clean Room Air Showers With Aluminum Swing Doors Control By IC Control Panel

MOQ: 1 set
Standard Packaging: plywood case
Delivery Period: about 15 days upon receipt of deposit
Payment Method: T/T, Western Union
Supply Capacity: 200 Set/Sets per Month
Detail Information
Place of Origin
Guangdong, China (Mainland)
Brand Name
Zhisheng
Certification
ISO 9001/CE/ROHS
Model Number
AS-1400T-1
Condition:
New
Dimension(WxDxH):
W1400xD1000xH2100mm
In Size(MM):
W800xD900xH1960mm
Weight:
280KG
Clean Room:
100 Class
Blowing Side:
Three Side Blowing
Material:
Power Coated Steel
Suitable:
One Person
Voltage:
380V, 50 Or 60Hz, 3PH
Warranty:
One Year
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Minimum Order Quantity:
1 set
Packaging Details:
plywood case
Delivery Time:
about 15 days upon receipt of deposit
Payment Terms:
T/T, Western Union
Supply Ability:
200 Set/Sets per Month
High Light:

air shower room

,

air shower clean room

,

Air Showers With Aluminum Swing Doors

Product Description

Only one door personal air shower room for single person, aluminum swing doors



Air shower.pdf



Features:



Product Personal air shower room for single person
External size W1400xD1000xH2100MM
Internal size W800*D900*H1960mm
Material: T=1.2 mm powder coated steel for main body and base
Doors type

only one W=800mm stainless steel single-leaf sliding door

Door closer  1 SET
Electric lock 1 SET
Indicator lights Green and red
Blower fan   1set,capacity: 1800CMH/set
99.99% HEPA filter  610*610*69mm 2 sets
Pre filter   2 pcs
Nozzles 6+6+4=16 pcs
Bloweing type Three -side blowing, wind speed: >24m/s
Control system Control by IC control panel
Photoelectric snesor Omron brand 1pcs
Philips LED light 1x18W



Description:



Cleanroom air shower  is a kind of partial purifying equipment of strong universality.





With novel structure, beautiful appearance, reliable running, low consumption, energy saving and convenient maintenance,



it is widely used in electron, machinery, medicine, foodstuff, color packing, brewage, biological engineering and other industry and scientific research fields.



It is usually installed between clean room and unclean room. When people and goods enter into clean room, they have to be blown at first.



The blown clean air can get rid of dust bough by people and goods and can effectively prevent dust source from entering into clean area.
Principle



The air inside of air shower is firstly filtered under the action of fan and enters into static pressure tank.



After filtered with high-efficiency air filter, clean air is jet out at high speed from the nozzle of air shower.



The nozzle angel is adjustable. It can effectively blow out dust attached on people and goods’ surface.



The blown dust enters into primary-efficiency air filter again, circulating so and reaching to the aim of air shower.

Full stainless steel Air shower/New Corner Air shower Air shower material



1. color steel plate



2. steel plate



3. stainless steel



Application: Stainless Steel Air Shower is usually used for Food , medicine, biological or other industry.



Standar size and specificaton:



Model Air shower Cargo Air shower
AS-1200D-1 AS-1400D-1 AS-1400D-1.5 AS-1400D-2 CAS-1700T-2 (2 Modules) CAS-1700T-4 (4 Modules)
Ex size WxDxH (MM) 1200x1000x 2050 1400x1000x 2050 1400x1500x 2050 1400x2000x 2050 1800x2000x2050 1800x4000x 2050
In size WxDxH (MM) 800x900x 1920 800x900x 1920 800x1400x 1920 800x1900x 1920 1200x1900x 1920 1200x3900x 1920
Doors Swing door/sliding door/shutter door Door frame: SS/ALU
Suitable person 1 1 1-2 2-3 Cart
Nozzles 12(two side) 12(two sides) 18(two sides) 24(two sides) 32(3- side) 64(3- side)
Fan #4250x1 set #4195 x 2 sets #4195x2sets #4250x2sets #4195x4sets #4195x8sets
Power(W) 1000W 850W 850W 2000W 1700W 3400W
HEPA filter 610x610x69 1pcs 610x610x69 2pcs 610x610x69 2pcs 915x610x69 2 pcs 610x610x69 4pcs 610x610x69 8pcs
Nozzle ф 25 or 32mm
Voltage 380V/50Hz/3Ph; 220V/50Hz/1Ph
Control system IC intelligent control panel, blowing automatically by photoelectric sensor, the two door are electric interlocked.



Note: Customer's size and specification can be acceptable.



Testing in factory:



All of equipment will be individually tested for safety and performance in accordance with international Standards before shipment. Each unit is shipped with a documentation outlining the tests undertaken and the units individual results for each unit.



Testing before shipment:

1. Appearance inspection

2. Electrical safety tests

3. Air wind speed testing

4. Function testing



Warranty:



The warranty of our equipment is for 1 year, but excluding consumable parts and accessories.

All equipment is shipped with a comprehensive use’s manual with testing report.

Additional IO/OQ/GMP document is available upon request.

Contact our sales representative for specific warranty details or document request.



Replacement parts:

1. HEPA filter: It should be changed in half or one year once.

2. Pre filter: It should be changed in 3-6 month once.



Air Shower's drawing:



Vertical Clean Room Air Showers With Aluminum Swing Doors Control By IC Control Panel 0

Vertical Clean Room Air Showers With Aluminum Swing Doors Control By IC Control Panel 1



Why you choose ZHISHENG Company ?



Professional service:



Fast reply in 12 hours if we receive any inquiry or request from customer

Familiar with equipment.

Technician or enginner can go to Southeast Asian countries for guiding insallation of machines. Like Thailand, Vietnam, Philipines, Malaysia and so on.





Delivery time:

Production period:15-30days

• Shipping notice or insurance for you after the goods is shipped.



After sales service:



We respect your feed back after receive the goods.

• We provide 1 year warranty after goods arrive.

• We promise all spare parts available in lifetime use.

• We care of your complain within 48hours.



Payment Term:

30% prepayment by T/T at order, the balance of payment before shipment.



Our Services

Cleanroom equipments,like air shower, FFU. It is one-year warranty.



Certificate:


We have CE and ROHS Certificate for air shower
