Anodized Aluminum Frame Disposable H13 H14 HEPA Filter Box With Fiberglass Media

Anodized Aluminum Frame Disposable H13 H14 HEPA Filter Box With Fiberglass Media

MOQ: 50 pieces
Standard Packaging: Carton and Pallet
Delivery Period: about 15 days upon receipt of deposit
Payment Method: Western Union, T/T
Supply Capacity: 500 pieces per month
Detail Information
Place of Origin
Guangdong, China (Mainland)
Brand Name
Zhisheng
Certification
ISO 9001, Rohs
Model Number
ZS-GY1170
Frame:
Anodized Aluminum
Separator:
Hot Glue
Size:
1170xx570x150mm
Type:
Box Type
Application:
Termina Of HVAC System
Class:
H13
Minimum Order Quantity:
50 pieces
Packaging Details:
Carton and Pallet
Delivery Time:
about 15 days upon receipt of deposit
Payment Terms:
Western Union, T/T
Supply Ability:
500 pieces per month
High Light:

Anodized HEPA Filter Box

,

Aluminum Frame HEPA Filter Box

,

Fiberglass Media HEPA Air Filter

Product Description

Disposable Terminal HEPA Filter box for Clean room, H13, H14 , Aluminum frame and fiberglass media​





Frame: Extruded aluminum

Media: fiberlgass

Size: 1170x5700x150mm



HEPA is a pleated mechanical air filter. It is an acronym for "HEPA [filter]" (officially defined by the U.S. Department of Energy). This type of air filter is theoretically capable of removing at least 99.97% of dust, pollen, mold, bacteria and any airborne particles 0.3 microns (µm) in size. A diameter specification of 0.3 microns responds to worst case; most penetrating particle size (MPPS). Larger or smaller particles are captured more efficiently. Using worst case particle sizes results in worst case efficiency ratings (i.e. 99.97% or better for all particle sizes).

All air filters require regular cleaning and filter replacement to function properly. Follow the manufacturer's recommendations for maintenance and replacement.



Disposable Terminal HEPA filter is by coordinating with the use of ceiling T-bar system, the disposable HEPA filter module unit can connect to air hose directly.



As for its small size, light weight, easy assembling, saving the installation time, it can be used for clean room or the other critical clean area which its cleanliness level is between class 1 and class 100,000.



Customized sizes and specifications are available to meet customer's requirements.



Features:

H

Low pressure drops

Thin in depth

Adjustable air flow

Easy installation

Negative pressure sealing



Usage:



It is considered especially suitable for applications in the ventilation and air conditioning system with limited space.



Material and operating conditions:

External frame Aluminum
Sealant Polyurethane
Separator Hot-melt
Filter media Fiberglass or HV fiberglass
Initial drop ≤220pa or 120pa
Maximum operating temperature 80℃
Maximum operating humidity 80%
Efficiency 99.99%





Standard size and specifications:

Model Outside dimensions(mm) Rated air flow (m3/h) Collar size
ZS-GY610 610x610x150 1000 200 mm ( 8")
ZS-GY915 915x610x150 1500 250mm ( 10")
ZS-GY1170 1170x570x150 1800 300mm ( 12")
ZS-GY1220 1220x610x150 2000 300mm ( 12")



Drawing:

Anodized Aluminum Frame Disposable H13 H14 HEPA Filter Box With Fiberglass Media 0



Pictures of Disposable Terminal HEPA filter:

Anodized Aluminum Frame Disposable H13 H14 HEPA Filter Box With Fiberglass Media 1Anodized Aluminum Frame Disposable H13 H14 HEPA Filter Box With Fiberglass Media 2



Payment Term:



40% prepayment by T/T at order, the balance of payment before shipment.



Packing:



Carton and Plywood Case



Delivery time:



Production period:15-30days

• Shipping notice or insurance for you after the goods is shipped.



After sales service:



We respect your feed back after receive the goods.

• We provide 1 year warranty after goods arrive.

• We care of your complain within 48hours.
