Air Supply Class 5 Laminar Flow Ceiling 2950*2500*500 For Hospital Operating Room

Air Supply Class 5 Laminar Flow Ceiling 2950*2500*500 For Hospital Operating Room
Air Supply Class 5 Laminar Flow Ceiling 2950*2500*500 For Hospital Operating Room Air Supply Class 5 Laminar Flow Ceiling 2950*2500*500 For Hospital Operating Room Air Supply Class 5 Laminar Flow Ceiling 2950*2500*500 For Hospital Operating Room

Large Image :  Air Supply Class 5 Laminar Flow Ceiling 2950*2500*500 For Hospital Operating Room

Product Details:
Place of Origin: Guangdong, China (Mainland)
Brand Name: Zhisheng
Certification: ISO9001
Model Number: ZS-TH01-000
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: plywood case
Delivery Time: about 15 days upon receipt of deposit
Supply Ability: 50 sets

Air Supply Class 5 Laminar Flow Ceiling 2950*2500*500 For Hospital Operating Room

Description
HEPA Filter: 8-10 Pieces Class: Class 5
Size: 2950*2500*500 Material: Cold Rolled Steel With Powder Coated
Air Supply: Side Or Top Air Supply Type: Ventilation
High Light:

stainless steel medicine cabinet

,

hospital room doors

Laminar Flow Air Supply ceiling for hospital operating room



Description:



It is HEPA filter efficiency up to 99.995% for 0.3um particles filtration, with the special design which specialized for hospital operation clean room ceiling can combine with operation special lights. Laminar flow ceiling comply with Biological contamination control system that can prevent the dust, particle, bacterial from the operating room, creating the high purification rank, appropriate temperature and humidity so that we have comfortable clean and safe environment.



Laminar Flow Air Supply Ceiling

In accordance with the purification class, laminar flow air supply ceiling is divided into Class

5/6/7/ 8 /9 (ISO14644-1) laminar flow air supply ceiling, or classified to burn ward, blood ward and ophthalmic operating room laminar flow air supply ceiling, etc.



Zhisheng series laminar flow air supply ceiling materials and advantages

  • Cold rolled steel with power coated and stainless steel materials can be selected by customers. The T type special aluminum configured with spring clip-on installation makes the maintenance and installation convenient and time-saving. The DPP equalizer net makes the air more uniform and gentle. The medium speed airflow compensation device is optional.



  • The high efficiency air filter can be decorated to two kinds of air supply, side air supply and roof air supply.
  • The non-standard dimension of laminar flow air supply ceiling can be made in case of special actual environment.

Application: Operating room



Purification class:



Class I laminar flow ceiling: 8-10pcs hepa filter

Class II laminar flow ceiling: 4-6pcs hepa filter

Class III laminar flow ceiling: 2-4pcs hepa filter



Size and Technical parameters



Product code Ceiling types

Ceiling dimension

(mm)

Hepa filter dimension QTY of Hepa filter (PCS)
ZS-TH01-000 Class 5 2950*2500*500 610*305*292(H14) 8 up to 10
ZS-TH02-000 Class 6 2600*1800*500 610*305*292(H14) 4 up to 6
ZS-TH03-000 Class 7/8/9 2600*1400*500 610*305*292(H13) 2 up to 4
ZS-TH03-001 Burn ward 2600*1400*500 610*305*292(H13) 3
ZS-TH01-000 Blood ward 2950*2500*500 610*305*292(H13) 8 up to 10
ZS-TH04-000 Ophthalmic operating room 1500*1500*500 610*305*292(H13) 4



Customized size is available



Structure:

Air Supply Class 5 Laminar Flow Ceiling 2950*2500*500 For Hospital Operating Room 0Air Supply Class 5 Laminar Flow Ceiling 2950*2500*500 For Hospital Operating Room 0

Air Supply Class 5 Laminar Flow Ceiling 2950*2500*500 For Hospital Operating Room 2
